Genelec 8020A

Description

>The Genelec 8020A is a very compact biamplified
active monitor system with performance
comparable to much larger systems.
The 8020A excels in applications where space
is at a premium, taking full advantage of the
unconventional design and advanced technologies
of Genelec’s 8000 Series loudspeaker
range.

Applications
• Near Field Monitoring
• Audio Video Post Production
• Mobile Vans
• Home Theaters
• Project / Home Studios
• Digital Workstations
• Multimedia Production and
Playback <

system specifications
8020A
Lower cut-off frequency, -3 dB < 65 Hz
Upper cut-off frequency, -3 dB > 21 kHz
Free field frequency response 66 Hz – 20 kHz (± 2.5 dB)
Maximum short term sine wave acoustic
output on axis in half space, averaged
from 100 Hz to 3 kHz @ 1 m > 96 dB SPL
@ 0.5 m > 102 dB SPL
Maximum long term RMS acoustic
output in same conditions with
IEC-weighted noise (limited by driver
unit protection circuit) @ 1 m > 95 dB SPL
Maximum peak acoustic output per pair
@ 1 m from the engineer with music
material > 105 dB
Self generated noise level in free field
@ 1 m on axis < 10 dB (A-weighted)
Harmonic distortion at 85 dB SPL Freq: 50…100 Hz < 3 %
@ 1 m on axis > 100 Hz < 0.5 %
Drivers Bass 105 mm (4″) cone
Treble 19 mm (3/4″) metal dome
Both drivers are magnetically shielded
Weight 3.7 kg (8.1 lb)
Speaker dimensions Height 242 mm (91/2″)
(including Iso-Pod table stand)
Height 230 mm (91/16″)
(without Iso-Pod table stand)
Width 151 mm (6″)
Depth 142 mm (55/8″).

Price Guide
Daily Hire: £10 each
Weekly Hire: £30 each
